Specifications
SURFACE
Fiber: Acid-dyed type 6,6 nylon
Construction: Cut pile
Weight: 32 ounces/yard2
Substrate: Freudenberg LUTRADUR polyester spunbond non-woven fabric (3.8 ounces/yard2)
BACKING OPTIONS
Material: Nitrile rubber (smooth, universal cleated, full cleated, or suction)
Thickness Options:
Standard 52-mil (body thickness 52-mil; border thickness 94-mil)
Medium duty 65-mil (body thickness 65-mil; border thickness 107-mil)
Heavy duty 90-mil (body thickness 90-mil; border thickness 90-mil)
Material: SBR rubber (smooth, universal cleated, full cleated, or suction)
Thickness:48-mil (body thickness 48-mil; border thickness 90-mil)
OVERALL MAT THICKNESS: 3/8 inch (0.375″)
STANDARDS & TESTING
- Passes standard for the surface flammability of carpets and rugs DOC-FF1-70
Cleaning Instructions
For the best results, utilize the following cleaning method to clean your Classic Impressions HD mat:
- Vacuum regularly (daily in high-traffic commercial areas; weekly in lower traffic areas).
- Extract or hose off as needed to remove heavy soil/debris.
- Hang mat to dry.
Always make sure the mat is dry before placing it back in service.
Design Specifications
Classic Impressions HD logo mats are produced using a layering process of color. Colors are typically matched to our standard pallet of 150 colors unless a specific coated PMS color is requested*.
Minimum Text Height: 1″ for serif fonts and 1/2″ for sans serif fonts
Minimum Line Thickness: 1/8″ except for white & light colors which should be at least 1/4″
These text requirements are for general use; however, special fonts and very thin letter forms may need to be made larger or thicker and will be approached on a case-by-case basis.
Light background colors should be avoided due to their tendency to show dirt on the mat more than a darker or neutral tone. We also advise against the use of screens, tints, and transparencies in the design because they are not easily converted to our color palette.
Mat Size Maximum Imprint Area
2′ x 3′ (24″ x 35″) 24″ x 35″
3′ x 4′ (35″ x 47″) 35″ x 47″
3′ x 5′ (35″ x 59″) 35″ x 59″
3′ x 10′ (35″ x 119″) 35″ x 119″
4′ x 6′ (45″ x 69″) 45″ x 69″
4′ x 8′ (45″ x 95″) 45″ x 95″
5′ x 8′ (59″ x 95″) 59″ x 95″
5′ x 10′ (59″ x 119″) 59″ x 119″
6′ x 10′ (69″ x 119″) 69″ x 119″
6′ x 12′ (69″ x 143″) 69″ x 143″
*We will do our best to match a PMS color, however, color matching can be extremely challenging. Although we can get close, color is never an exact science and variations will occur . An exact color match is vulnerable to many factors. One factor is that we are printing on white nylon carpet. Another factor is that we use a hot press to combine the carpet and rubber backing. Heat from the press often causes the color to lighten. Typically, we can get close to most PMS colors, but the final color may be a few shades off. For the PMS color to be as close as possible, we require additional time to create the proof sketch. Specific PMS colors may be matched for a one-time additional fee.
Available Sizes
2′ x 3′ (24″ x 35″)
3′ x 4′ (35″ x 47″)
3′ x 5′ (35″ x 59″)
3′ x 10′ (35″ x 119″)
4′ x 6′ (45″ x 69″)
4′ x 8′ (45″ x 95″)
5′ x 8′ (58″ x 95″)
5′ x 10′ (58″ x 119″)
6′ x 10′ (68″ x 119″)
6′ x 12′ (68″ x 143″)
Special sizes available in widths of 3′ (35″), 4′ (45″), 5′ (58″), or 6′ (68″) and lengths up to 40′.
Please note, mat sizes are approximate as rubber shrinks and expands in conjunction with temperature and time. Tolerable manufacturing size variance is 3-5%.
