Description

Product Information

LOGO SEARCH
More Pictures

General Information

Colorstar Impressions HD Logo Mats are made from PET (polyethylene terephthalate) carpet surface contains 100% recycled content reclaimed from plastic.
Low profile rubber edging helps the Colorstar Impressions HD mat to always lay flat and is resistant to curling or cracking.
Specify the Colorstar Impressions HD Logo Mats when fine details, shading and 3-D images are desired.
A high quality logo mat designed to provide wiping and moisture absorption.
3/16″ total thickness
HD logos are achievable utilizing a state-of-the-art digital printer.
Logos and designs are digitally printed at 76 dpi on 32-ounce per square yard carpet, making fine details, shading, and 3D images achievable
All Colorstar Impressions HD mats are Certified Slip resistant by the National Floor Safety Institute.
A great INDOOR entrance mat for medium to heavy traffic areas.
Gripper Backing is available for placement on carpet, or specify a Smooth backing for use on hard floor surfaces.
Available in 2′ 6″, 3′, 4′, 5′, and 6′ widths up to 40′ in length. 6′ widths available in SMOOTH BACKING ONLY.
Custom shapes and sizes are attainable upon request.
Common Use: Commercial buildings, Hotels, Restaurants, Healthcare facilities, Office buildings and more!

Steps On How to Order Colostar Impressions HD Logo Mats:

Fill out the quote form above noting quantity (Quantity Discounts Available), type of backing (Cleated or Smooth).
You will be provided with an Artwork Proof for your approval within 24 – 36 business hours.
Once Artwork is approved and signed off – All we need is your contact information and where you want it shipped.
Your mat(s) will shipped/delivered within 1-3 weeks After Receipt of Order is confirmed.

Color Options

Color Selection for Colorstar Impressions HD Logo mats from Mad Matter, Inc.

Specifications

SURFACE
Material: PET (polyethylene terephthalate) printed/disperse-dyed yarn
Weight: 32 ounces/yard²
Construction: Cut pile
Substrate: Freudenberg LUTRADUR® polyester spunbond non-woven fabric 3.8 ounces/yard² (130 grams per square meter)

BACKING OPTIONS
Material: Nitrile rubber – smooth, universal cleated or suction
Thickness Options:
Standard duty 52-mil (body thickness 52-mil; border thickness 94-mil)
Medium duty 65-mil (body thickness 65-mil; border thickness 107-mil)
Heavy duty 90-mil (body thickness 90-mil; border thickness 90-mil)

Material: SBR rubber – smooth or full cleated
Thickness: 48-mil (body thickness 48-mil; border thickness 90-mil)

Overall Mat Thickness: 3/8 inch (0.375″)

STANDARDS & TESTING

Certified high-traction by the National Floor Safety Institute (NFSI)
Passes flammability tests EN ISO 11925-2 (2010) and EN ISO 9239-1 (2010).
Passes BS 4790 (1987) determination of the flammability of textile floor coverings.

Cleaning Instructions

ColorStar Impressions HD mats can be cleaned in several different ways:

They can be commercially laundered (see Laundering Instructions)
Vacuumed regularly (daily in high-traffic areas; weekly in lower-traffic applications)
Cleaned with an extractor, or hosed off as necessary to remove heavy soil
Hang to dry

Mats should always be dry before they are placed back in service.

Design Specifications

ColorStar Impressions HD logo mats are produced using a layering process of color. Colors are typically matched to our standard pallet of 150 colors. PMS color matching is not available.

Minimum Text Height: 1″ for serif fonts and 1/2″ for sans serif fonts
Minimum Line Thickness: 1/8″ except for white & light colors which should be at least 1/4″
These text requirements are for general use; however, special fonts and very thin letter forms may need to be made larger or thicker and will be approached on a case-by-case basis.

Light background colors should be avoided due to their tendency to show dirt on the mat more than a darker or neutral tone. We also advise against the use of screens, tints, and transparencies in the design because they are not easily converted to our color palette.

Mat Size                             Maximum Imprint Area
2′ x 3′ (24″ x 35″) 23″ x 34″
3′ x 4′ (35″ x 47″) 34″ x 46″
3′ x 5′ (35″ x 59″) 34″ x 58″
3′ x 10′ (35″ x 119″) 34″ x 118″
4′ x 6′ (45″ x 69″)                    44″ x 68″
4′ x 8′ (45″ x 95″)                    44″ x 94″
5′ x 8′ (58″ x 95″)                    57″ x 94″
5′ x 10′ (58″ x 119″)                    57″ x 118″
6′ x 10′ (68″ x 119″)                    67″ x 118″
6′ x 12′ (68″ x 143″)                    67″ x 142″

Backing Type

Available Sizes

Special sizes available in widths of 3′ (35″), 4′ (45″), 5′ (58″), or 6′ (68″) and lengths up to 40′.

Please note, mat sizes are approximate as rubber shrinks and expands in conjunction with temperature and time. Tolerable manufacturing size variance is 3-5%.

2′ x 3′ (24″ x 35″)
3′ x 4′ (35″ x 47″)
3′ x 5′ (35″ x 59″)
3′ x 10′ (35″ x 119″)
4′ x 6′ (45″ x 69″)
4′ x 8′ (45″ x 95″)
5′ x 8′ (58″ x 95″)
5′ x 10′ (58″ x 119″)
6′ x 10′ (68″ x 119″)
6′ x 12′ (68″ x 143″)

Literature

Colorstar Impressions HD Literature

Colorstar Impressions HD Logo Mats
